wind power
Powerful, portable cutting tools
Simplex’s HCC-Series Cable Cutters consists of ten models in three tool configurations designed to quickly, cleanly, and reliably cut cable and
wire rope from 0.71" to 4.72" diameter, including lead, underground, and telephone-grade cable, plus steel and aluminum wire rope. Capacity in the models ranges from 7.9 to 43.8 tons with a maximum pressure of 10,150psi. Each model offers advanced performance and productivity features such as spring-return cylinders or the increased cutting control of a double-acting cylinder on the 43.8 ton HCCD model. Two handheld HCCP models feature integrated pumps requiring no external pump or power supply.
Simplex /// www.tksimplex.com
Long reach, live line, cable cutter
BURNDY announced the release of the PATRIOT PATCUT954HS Long Reach, Insulated, Hydraulic Cable Cutting tools. The PATCUT954HS Hot Stick Cable Cutter (available in 82" and 94" lengths) provides users both increased flashover protection and extended reach for live line cutting. The large capacity C-Head
is designed to hook onto conductors, stabilizing the tool for easy cutting,
up to 954kcmil ACSR. Designed for safety, convenience, and function, the PATCUT954HS series of battery-operated tools perform cuts in less than 15 seconds, minimizing exertion and time required. The pistol grip and adjustable assist handle allow for extra control when operating overhead, while the rapid advance ram reduces time on live lines, adding to the overall ergonomics and safety of the system. Large on/off triggers and hand grip area also enhance user experience. The PATCUT954HS features protected electronic circuitry, the robust and reliable INFINITY DRIVE transmission, and a patented high-speed hydraulic pump system. Powered by Makita 18V, 3.0Ah or 5.0Ah lithium-ion batteries for long-lasting power, the PATCUT954HS is multi-Ah capable, accepting 2.0Ah through 6.0Ah sizes. A lifetime warranty on the INFINITY DRIVE is included, along with a 5-year limited warranty for the tool (excluding blades and the pole itself ), and a 3-year limited warranty on the batteries and charger.
BURNDY /// www.burndy.com
Whether you need a system for wind blade production or repairs, contact us today to learn how Mankiewicz can provide your complete coatings solutions.
North America: +1 (843) 654 7755 Europe: +49 (0) 40 / 75 10 30
www.mankiewicz.com
Fall protection and rescue in confined spaces
Pure Safety Group (PSG) has introduced the Checkmate TR3 Tripod, used as Personal Protective Equipment to access workers and provide fall protection in confined space environments. The tripod features a new crown and foot design that makes it strong yet lightweight. The TR3 is the first Checkmate product to be launched in North America. The TR3 tripod legs lock in the open position automatically during use and easily disengage for folding, and are adjusted for proper height with captive pins. Detent pins secure them to the tripod using PVC-coated keeper wires. The tripod’s pivoting spiked feet and rubber soles allow
for its use on soft or hard surfaces. Its anti-splay webbing, which prevents the tripod legs from splaying under a
load, can be neatly tucked into their own housing slot for storage. When used in conjunction with other Checkmate equipment, the TR3 can be used as an anchorage for suspended work and winch operations and as a secure fall arrest point. The tripod’s maximum single-user weight for fall arrest, with one operator, is 310lbs (141kg). When used in assisted rescue, the maximum combined capacity load for workers is 620lbs (281kg) and, for carrying goods, is 550lbs (250kg). The tripod meets OSHA standards, exceeds ANSI standards, and will be CSA-certified.
Pure Safety Group (PSG)
/// www.puresafetygroup.com
Round slings with high-performance fibers and flex hose
The newly developed DoMega+ makes handling heavy-duty round slings easy. The round sling is made of ultra-high- molecular-weight polyethylene (UHMW-PE) and the new silver-grey cross-elastic round sling hose is made of polyester, which wraps tightly around the yarn core, thus ensuring a very low wrinkling, compact design. This means that DoMega+ round slings do not get crushed even in smaller crane hooks
and attachment points. Due to the reduced internal pressure
in the hose and a special fabric construction formulated for abrasion resistance, the DoMega+ demonstrates low wear and a long service life. The additional effect of the flexible hose is that the yarn core is able to expand better under load at the contact surface. The DoMega+ is currently available in the carrying capacities 10 to 50 t and is supplied as standard with an RFID transponder and a transparent extra protective hose for the standard label. The RFID transponder (HF, 13.56 MHz, I-Code SLI, ISO 15693) can be used to clearly assign tests, for example, and their digital documentation to the product. The transponder is easily readable and writeable with an NFC-enabled reader.
DolecoUSA /// www.doleco-usa.com
