Racking system for bifacial PV modules and green roofs

AEROCOMPACT has developed a flat roof system for mounting bifacial active PV modules or solar systems on green roofs. CompactFLAT GS can be used to install framed modules on foil and bitumen roofs, with and without thermal insulation under the roof sealing, as well as on concrete and gravel roofs. While CompactFLAT GS15 has a tilt angle of 15° and is suitable for installing solar systems with south orientation, AEROCOMPACT has designed the CompactFLAT GS10PLUS system with a tilt angle of 10° for east/west orientation. With south orientation, there is no need for a wind deflector that prevents the reflection of light. Since it has a distance to the roof surface of around 40cm, the CompactFLAT GS system is also well suited for green roofs. The aerodynamic mounting system consists of few components and does not require long rails, making it quick and easy for an installer to mount. AEROCOMPACT provides a 25-year warranty on the system, which will be available in North America by the end of Q4 2022.

AEROCOMPACT | www.aerocompact.com




Volume: 2022 November/December
