solar product spotlight: modules
SunWize Power & Battery Product: SunWize SWPB-320W-C1D2 Solar
Module
Application: Industrial
Maximum Power (Pmax): 320W
Maximum Power Point Voltage (Vmpp):
38.31V
Maximum Power Point Current (Impp):
8.36A
Open Circuit Voltage (Voc): 45.44V
Short-Circuit Current (Isc): 8.36A
Max. System Voltage: 600V
Power Tolerance: 0% / +3%
Cell Type: 72
Weight: 46.3lbs (21.6kg)
Dimensions: 38.9" x 77.01" x 1.97" (988mm x 50mm x 1956mm)
Tests/Certifications: UL 1703, Class 1 Division 2 Group A,B,C, and D
www.sunwize.com
Shenzhen Crystal Solar Co., Ltd.
Product: Bifacial (flexible) solar panel Application: Utility-scale, recreation Maximum Power (Pmax): 389W
Maximum Power Point Voltage (Vmpp): 39V Maximum Power Point Current (Impp): 10A Open Circuit Voltage (Voc): 46.8V Short-Circuit Current (Isc): 11A
Module Efficiency: 21%
Operating Temperature Range: -22°F to
158°F (-30°C to 70°C)
Normal Operating Cell Temperature (NOCT): 25°C
Max. System Voltage: 200V Power Tolerance: 5%
Cell Type: Bifacial solar cell Frame: Aluminum
Weight: 66lbs (29.9kg)
Dimensions: 77" x 39" x 0.12" (1956mm x
992mm x 3mm)
Max Load: 500lbs (227kg) Tests/Certifications: ROHS, CE, FCC Warranty: 5-year warranty www.crystal-solar.com
32.8V
Maximum Power Point Current (Impp):
9.6A
Open Circuit Voltage (Voc): 39.7V
Short-Circuit Current (Isc): 10.0A
Module Efficiency: 19.0%
Operating Temperature Range: -40°F to 185°F (-40°C to 85°C)
Normal Operating Cell Temperature (NOCT): 45°C +/-2°C
Atlantic Clean Energy Supply, LLC (ACES)
Product: 260W bifacial
Application: Residential, commercial, industrial,
utility-scale
Maximum Power (Pmax): 260W
Maximum Power Point Voltage (Vmpp):
38.91V
Maximum Power Point Current (Impp):
9.71A
Open Circuit Voltage (Voc): 47.55V
Short-Circuit Current (Isc): 9.25A
Module Efficiency: 18%
Operating Temperature Range: -40°F to 185°F (-40°C to 85°C)
Normal Operating Cell Temperature (NOCT): 45°C +/-2°
Max. System Voltage: 1500VDC (IEC) Power Tolerance: 0 / +5V
Cell Type: Bifacial
Glass: Double glass
Frame: Aluminum
Weight: 65.7lbs (29.8kg) +/-3%
Dimensions: 78.9" x 39" x 1.18" (2004mm x 1000mm x 30mm)
Max Load: 2400Pa (front and back) Tests/Certifications: ETL
Warranty: 12-year product warranty, 30-year linear power output warranty
www.atlanticces.com
Max. System Voltage: 1500V
Power Tolerance: -0/+3%
Cell Type: Monocrystalline PERC half-cut
Glass: 3.2mm
Frame: Aluminum anodized black
Weight: 40.8lbs (18.5kg)
Dimensions: 65.95" x 39.06" x 1.38" (1975mm x 992mm x 35mm)
Max Load: 5400Pa snow / 2400Pa wind Tests/Certifications: UL1703, IEC61215 Warranty: 25-year warranty www.certainteed.com/solar
Vikram Solar, Ltd.
Product: Somera Duplex N-Type Bifacial
Application: Commercial, industrial, utility- scale, agro-industry, sound barriers
Maximum Power (Pmax): 395W
Maximum Power Point Voltage (Vmpp): 43V
Maximum Power Point Current (Impp):
9.18A
Open Circuit Voltage (Voc): 50.5V
Short-Circuit Current (Isc): 9.83A
Module Efficiency: 20.16%
Operating Temperature Range: -40°F to 185°F (-40°C to 85°C)
Normal Operating Cell Temperature (NOCT): 46°C
Max. System Voltage: 1500V
Power Tolerance: 3%
Cell Type: Monocrystalline N-type bifacial 5BB
Glass: 2.5mm (0.098") high transmission
Weight: 59.525lbs (27kg)
Dimensions: 77.76" x 39.05" x 0.23" (1975mm x 992mm x 6mm)
Max Load: 2400Pa Tests/Certifications: UL 61703,
IEC:61730:2016, IEC 61215:2016 Warranty: 30-year warranty www.vikramsolar.com
CertainTeed
Product: CT Series Module 120 half-cell
Application: Residential Maximum Power (Pmax): 315W
Maximum Power Point Voltage (Vmpp):
High Performance Solar Modules
15
• AXIblackpremium HC 310-315MH/120S – ALL BLACK • AXIpremium HC 380-385MH/144S
• AXIpremium BLK 320MH/120S
We have modules availability
AXITEC, LLC, 1819 Underwood BLVD, Suite 5, Delran, New Jersey 08075, Phone 856-393-7800, [email protected]
